CRGO AMDT Single Phase Pole Transformer
所属分类：
Product Center
Power Transformer
Single Phase Transformer
库存剩余
隐藏域元素占位
- Description
-
- Commodity name: CRGO AMDT Single Phase Pole Transformer
- Commodity ID: CRGO AMDT Single Phase Pole Tran
Summary
The FULE overhead transformer may be used alone for the supply of a single phase load or as one of three units in a bank for the supply of a three phase load. Our single phase overhead distribution transformer is commonly used in various places including rural areas, remote regions and scattered villages to provide high quality power supply for daily lighting, agricultural production and industrial plants. grid.etc
Product Description
Standards
IEEE & ANSI C57 12.00, IEEE IEEE & ANSI C57 12.20, & ANSI C57 12.90
Product Range
kVA :
10 through 500
Polarity:
Additive or subtractive
Temperature rise:
65°C
Primary voltage:
2400V through 34500GrdY/19920V
Cooling type:
ONAN
Secondary voltage:
120/240V,240/480V, 139/277V,600V
Single phase-Hert:
60&50
Taps:
±2×2.5% HV side
Specification
> CSP Series with C.R.G.O wound Core Capacity
(kVA)Primary
Rating
(V)Amorphous core CRGO core No load loss(W) Load loss(W) No load loss(W) Load loss(W) 3 8 45 9 45 5 8 75 19 75 10 12 120 36 120 15 15 195 50 195 25 18 290 80 290 37.5 30 360 105 360 50 32 500 135 500 75 45 650 190 650 100 50 850 210 850 167 65 1410 350 1410 Note:*The above parameter is only subject to our standard design,special requirement can be customized
