SCBH15 Amorphous Dry Type Transformer
所属分类：
Product Center
Power Transformer
Dry-type Transformer Series
库存剩余
隐藏域元素占位
- Description
-
- Commodity name: SCBH15 Amorphous Dry Type Transformer
- Commodity ID: SCBH15 Amorphous Dry Type Transf
Summary
The dry-type transformer is without oil, so it is no danger of burning and can be installed indoor as well as be entered into load center to meet the needs of high-density load development in modern metropolises.
Product Description
Product FeaturesThis product possess such advantages as low no-load loss, no oil, flame retardation and self-extinguishing, moisture resistance, crack resistance, maintenance-free etc. Can be used to replace all common dry-type transformers which now are used in many places. They can used in high buildings, commerce centers, subways, airports train stations, enterprises and power plants. They are especially suitable for installing and using in such places where strict fireproof requirements, including anti-combustible and anti-explosive, must be met.
SpecificationProducts standard :
GB/T 10228-2015, GB20052-2020
Tapping range of high-voltage : ±5% or ±2×2.5%
Core : Core-type Transformer
Enclosure : IP20/IP23
Rated high-voltage : 10(11, 10.5, 6.6, 6.3, 6)kV
Insulating level : LI75AC35/LI0AC5
Winding Type : Two-winding Transformer
Winding : Cooper/Aluminium
Rated low-voltage : 0.4kV
Frequency : 50Hz
Usage : Single-phase Transformer, Combined Transformer, Power Transformer, Distribution Transformer
Frequency Characteristics : , High Frequency
Connection group : Dyn11 or Yyn0
Winding :Cooper/Aluminium
Shape of Core : U
Capacity : 30-2500kVA
Rated
capacity
(KVA)Voltage combination and tapping range Lable of
connecting
groupNo-Load
loss
(W)Load
loss
(W)No-Load
current
(%)Impedance
Volitage
(%)High-
Voltage
(kV)High voltage
tapping range
(%)Low-
Voltage
(kV)30 6
6.3
10
10.5
11±5±2x2.5 0.4 Dyn11 70 710 1.6 4 50 90 1000 1.4 80 120 1380 1.3 100 130 1570 1.2 125 150 1850 1.1 160 170 2130 1.1 200 200 2530 1.0 250 230 2760 1.0 315 280 3470 0.9 6 400 310 3990 0.8 500 360 4880 0.8 630 420 5880 0.7 630 410 5960 0.7 800 480 6960 0.7 1000 550 6130 0.6 1250 650 9690 0.6 1600 760 11730 0.6 2000 1000 14450 0.5 2500 1200 17170 0.5 1600 760 12960 0.6 8 2000 1000 15960 0.5 2500 1200 18890 0.5
